Isolation Improves Application Performance

New Product Also Eliminates Ground Loops

Microstar Laboratories uses this image to illustrate the June 3, 2008 press release.

Microstar Laboratories suggests this text to go with the available image:

When signal isolation matters, when eliminating ground loops is important, when compact packaging helps, and when your application has – or could have – many channels, take a look at the MSXB 084 for isolated analog inputs.

Download 7.35MB TIFF.

MSXB 084 analog input isolation board photo
